FRANKEN

Refrigerated plug-in multideck with large display area

BENEFITS AT A GLANCE

A narrow & wide plug in multideck for impulse sales

  • LED illumination highlights goods to help increase impulse sales
  • Specially designed for easy relocating makes the cabinet ideal for seasonal offers and promotions
  • From kiosk to supermarket, it is easy to find the space for this cabines
  • Service-friendly design and energy saving accessories

Improved energy efficiency

  • Internal LED lighting
  • EC fans

* The information on the energy class (according to EU regulations 2019/2018 and EU 2019/2024) reported here refers to standard models and precise product configurations and set-ups. The site is based on the information available at the time of publication. As the energy class depends on the specific product configuration, despite the efforts made to ensure the greatest possible accuracy, the real data can differ significantly from the data declared here. For further information, we invite you to consult the European Product Database for Energy Labelling (EPREL) or to contact our Sales Office.

  • Product Category

    MULTIDECK

  • Operation Mode

    PLUG IN

  • Refrigant

    R404a, R452a, R290a

  • Category



  • Temperature Classes

    M1 / M2 / H1

  • Small but tall, highly flexible multideck

    Optimally suited to your needs: The plug-in Franken units are ready to use and offer the perfect solution for every store. Its integrated refrigeration circuit lets you set up the units wherever needed on the sales floor. Franken displays your products wherever you want. The removable, energy-optimized condensing unit and energy-saving regulator make your products both economical and environmentally friendly.

  • Standard Features

    • Open front chiller designed for beverages, fruits and vegetables and pre-packed cheese
    • Max 5 rows of display shelves with 40 mm scanner pricing rails with LED shelf lighting
    • Forced-air cooling
    • Electronic control with storage temperature readout
    • Stainless steel bumper in three versions
    • LED lighting of signage header and horizontal, canopy and shelves
    • Manual nightblind
    • Adjustable display height and inclination (0°, 10°, 20°)

    Accessories / options

    • Energy-saving EC fans
    • EC evaporator fan
    • Also available with hinged or sliding doors
    • Upon request, also suitable for connection to refrigeration systems
  • Dimensions (mm)

    Height: 2000, 2.200
    Lenght: 937, 1.250, 1.875, 2.500
    Depth: 671, 900

  • Franken Brochure
